Digital handheld galvanized Paint depth Gauge Galvanizing Thickness Measurement
$445.15$893.95
Payment Methods
Product Description
| Measuring Range
|
0-1500µm (0-1.5mm) or 0-60mil
| Resolution
|
0.1µm (0-99.9 µm) and 1µm (over 100 µm)
|
| Color
|
Blue ,Black ,Red ,Yellow
| Application
|
measuring coating thickness
|
| Accuracy
|
±1-2% (±2.5µm or 0.1mil - whichever the greater)
| Certification
|
CE, RoHS
|
| Power supply
|
2 x 1.5V AA Batteries
| Warranty
|
1 years
|
| Item Name
|
coating thickness gauge
| Minimum Measurement Area
|
5mm
|
| Minimum Sample Thickness
|
0.3mm
| MOQ
|
1 Piece
|
| Model Number
|
GTS820F
| Operating Conditions
|
Temp: -10 - 50ºC and Humidity: < 85%
|
| Weight
|
97g ( including batteries)
| Dimensions
|
126 x 69 x 35mm
|
Features
1.Thickness measurement using Magnetic Method to measure the non-magnetic coating on a magnetic metal substrate.
2.Single-point or two-point method could be used to correct probe system deviation, in order to ensure the accuracy of the device in the process of measuring.
3.Power voltage indicator.supply by USB 5V or 2 AA batteries (AA)
4.Speaker beep while operating.
5.Power-off automatically when idle; manually power-off available.
6.Negative display function to ensure the accuracy of zero point calibration.
7.Ultra-low power consumption, less than 10 μA in standby mode.
8.Operation method: Graphic menu button operation
9.Human-computer interaction: buttons, backlight dot matrix screen, light, buzzer
10.Data transfer: USB, Bluetooth
11.PC software: Windows PC, Android App , iOS App
Detailed Images
